fusion dielectric d-ring 23kn non-conductive connector
FP-2020-DE Straight Dielectric D Ring
fusion dielectric d-ring 23kn non-conductive connector
fusion dielectric d-ring 23kn non-conductive connector
FP-2020-DE Straight Dielectric D Ring

FP-2020-DE Straight Dielectric D Ring

FP-2020-DE-BLK

MSRP
Regular price$20.00
/
Shipping calculated at checkout.

The Straight Dielectric D-Ring combines a heat-treated steel core with a non-conductive polymer overmold for compatible dielectric equipment assemblies. The straight base provides a slotted connection for compatible webbing. The polymer overmold has a dielectric resistance rating of at least kN.



• Product Number: FP-2020-DE-BLK



Body and Configuration

• Material: Heat-treated steel core with non-conductive polymer overmold.

• Shape: Straight D-ring.



Size and Weight

• Dimensions: Height 87 × width 87 mm (3.43 × 3.43 in).

• Thickness: 13 mm (0.51 in).

• Opening Size: Ring inner diameter: 57 mm (2.24 in); slot width: 51 mm (2.01 in).

• Weight: 164 g / approximately 5.79 oz.

• Color: Black.



Mechanical and Electrical Ratings

• Minimum Breaking Strength: 23 kN.

• Proof Load: 16 kN.

• Dielectric Rating: At least 9 kN.

• Standard: meets ANSI Z359.12-2019; CSA Z259.12-16.
